Description
T-Series Parameter Standard | ||
| Model | T6 | T10 |
| Battery Capacity | 48V 18Ah | 60V 18Ah |
| Range | 40-70km | 30-75km |
| Maximum Speed | 25km/h (48km/h lift-off) | 25km/h (60km/h lift-off) |
| Motor Power | 600W | 1000W*2 |
| Frame Material | Aluminum Alloy | |
| Brake System | Front and Rear Mechanical Disc Brakes | Front and Rear Hydraulic Brakes |
| Front shock absorber | Hydraulic spring shock absorber | |
| Rear Shock Absorption | Hydraulic Spring Shock Absorption | |
| Tires | 10 inch pneumatic off-road tires | |
| Maximum load | 120kg | |
| Climbing degree | 25° | 35° |
| Charging time | 8-10h | 8-10h |
| Expanded size | 1230*630*1305mm | |
| Folded size | 1170*630*540mm | |
| Net weight | 25.6kg | 29.6kg |
| Gross weight | 30.7kg | 34.5kg |
| Packing size | 1190*245*500mm | |
